Part Number: AO4614
MFG: AO
Package Cooled: SOP-8
D/C: 09+
Description: The AO4614 uses advanced trench technology MOSFETs to provide excellent RDS(ON) and low gat...
- Table of contents:
AO4614
-
Suppliers
DataSheet
General Description
AO4614 General Description
The AO4614 uses advanced trench technology MOSFETs to provide excellent RDS(ON) and low gate charge. The complementary MOSFETs may be used in H-bridge, Inverters and other applications. Standard Product AO4614 is Pb-free (meets ROHS & Sony 259 specifications). AO4614L is a Green Product ordering option. AO4614 and AO4614L are electrically identical.
AO4614 Maximum Ratings
|
Parameter |
Symbol |
Max n-channel |
Max n-channel |
Units | |
| Drain-Source Voltage Gate-Source Voltage |
VDS VGS |
40 ±20 |
-40 ±20 |
V V | |
| Continuous Drain Current A |
TA=25°C TA=70°C |
ID |
6 5 |
-4 -5 |
A |
| Pulsed Drain CurrentB |
IDM |
20 |
-20 | ||
| Power Dissipation | TA=25°C TA=70°C |
PD |
2 1.28 |
2 1.28 |
W |
| Junction and Storage Temperature Range |
TJ, TSTG |
-55 to 150 |
-55 to 150 |
°C | |
AO4614 Features
·n-channel p-channel
·VDS (V) = 40V -40V
·ID = 6A (VGS=10V) -5A (VGS = -10V)
·RDS(ON) RDS(ON)
·< 31mΩ (VGS=10V) < 45mΩ (VGS = -10V)
·< 45mΩ (VGS=4.5V) < 63mΩ (VGS = -4.5V)
·VDS (V) = 40V -40V
·ID = 6A (VGS=10V) -5A (VGS = -10V)
·RDS(ON) RDS(ON)
·< 31mΩ (VGS=10V) < 45mΩ (VGS = -10V)
·< 45mΩ (VGS=4.5V) < 63mΩ (VGS = -4.5V)
