AP432 Product Image

AP4 Series Datasheet download

Five Points

Part Number: AP432



MFG: AP

Package Cooled: TO-92

D/C: 03+

Description: The AP432/432A are 3-terminal adjustable precision shunt regulators with guaranteed stable temperature over the applica...


Urgent Purchase

AP432 General Description


The AP432/432A are 3-terminal adjustable precision shunt regulators with guaranteed stable temperature over the applicable extended commercial temperature range. The output voltage
may be set at any level greater than 1.24\/ (VREF) up to 20V merely by selecting two external resistors that act as a voltage divider network. These devices have a typical output impedance of 0.2. Active output circuitry provides very sharp turn-on characteristics, making these devices excellent improved replacements for Zener diodes in many applications.

The precise +/- 1% reference voltage tolerance of the AP432/432A make it possible in many applications to avoid the use of a variable resistor, consequently saving cost and eliminating drift and reliability problems associated with it.

AP432 Maximum Ratings

                     Cathode Voltage........................ 20V
    Continuous cathode current ................. 10mA ~ 250mA
 Reference input current range ......................  10mA
  Operating temperature range (AP432) .............  -20oC ~ 85oC
                                                 (AP432I...............-40oC~85oC
                    Lead Temperature..................... .260oC
               Storage Temperature ................    -65oC ~ 150oC
Power Dissipation (Notes 1. 2)      SOT89 ................  0. 80W
                                                      TO92............                 0.78W
                                                      SOT23 .................0.25W
                                                      SOT25................. 0.25W
                                                      SOP..................   0.6W

AP432 Features

- Precision reference voltage
     AP432 : 1.24V ± 1%
     AP432A : 1.24V ± 0.5%
- Sink current capability: 200mA.
- Minimum cathode current for regulation: 150A
- Equivalent full-range temp coefficient: 30 ppm/oC
- Fast turn-on Response.
- Low dynamic output impedance: 0.2
- Programmable output voltage to 20v
- Low output noise
- Packages: SOT89, SOT23, SOT25, SOP8 and TO92
