Position: Home > Datasheet list > AP8 Series > Index A > AP8802SG-13
Electronica China

Purchase AP8802SG-13, In-stock AP8802SG-13 From SeekIC.

MFG:Diodes Inc (VA)  Category:Integrated Circuits (ICs)

AP8802SG-13

AP8 Series Datasheet download

Five Points

Part Number: AP8802SG-13

Category: Integrated Circuits (ICs)

MFG: Diodes Inc (VA)





Descriptions: IC CONV LED STP DWN 1A 8-SOP

Price Break

1
25
100
250
500
1000

Unit Price

2.12000
1.61280
1.41120
1.26000
1.15920
.88200

Extended Price

2.12
40.32
141.12
315.00
579.60
882.00

(All prices are in USD) Prices for reference only
Urgent Purchase

AP8802SG-13 General Description

IC CONV LED STP DWN 1A 8-SOP

AP8802SG-13 Parameters

Technical/Catalog InformationAP8802SG-13
VendorDiodes Inc (VA)
CategoryIntegrated Circuits (ICs)
Package / Case8-SOIC (3.9mm Width)
PackagingCut Tape (CT)
Current - Output / Channel1A
Number of Outputs1
TypeBacklight, White LED
Voltage - Supply8 V ~ 48 V
Voltage - Output48V
TopologySwitched Inductor, Step-Down (Buck)
Frequency500kHz
Operating Temperature-40°C ~ 105°C
Efficiency92%
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names AP8802SG 13
AP8802SG13
AP8802SGDICT ND
AP8802SGDICTND
AP8802SGDICT
