Part Number: AP95T07GP









Description: Advanced Power MOSFETs from APEC provide the designer with the best combination of fast switching, rug...


Urgent Purchase

AP95T07GP General Description


Advanced Power MOSFETs from APEC provide the designer with the best combination of fast switching, ruggedized device design, low on-resistance and cost-effectiveness.

The TO-220 package is widely preferred for commercial-industrial power applications and suited for low voltage applications such as DC/DC converters.

AP95T07GP Maximum Ratings

Symbol Parameter Rating Units
VDS Drain-Source Voltage 75 V
VGS Gate-Source Voltage ±20 V
ID@TC=25 Continuous Drain Current, VGS @ 10V3 80 A
ID@TC=100 Continuous Drain Current, VGS @ 10V 70 A
IDM Pulsed Drain Current1 320 A
PD@TC=25 Total Power Dissipation 300 W
  Linear Derating Factor 2 W/
EAS Single Pulse Avalanche Energy4 450 mJ
TSTG Storage Temperature Range -55 to 175
TJ Operating Junction Temperature Range -55 to 175
