Part Number: AS179-92LF
Description: PHEMT GaAs IC SPDT Switch DC3 GHz The AS179-92 is an IC FET SPDT switch in a low cost miniature SC-70 6 lead pla...
- Table of contents:
AS179-92LF
-
Suppliers
DataSheet
General Description
AS179-92LF General Description
PHEMT GaAs IC SPDT Switch DC3 GHz
The AS179-92 is an IC FET SPDT switch in a low cost miniature SC-70 6 lead plastic package. The AS179-92 features low insertion loss and positive voltage operation with very low DC power consumption. This general purpose switch can be used in a variety of telecommunications applications.
AS179-92LF Maximum Ratings
- P1 dB +30 dBm Typical @ +3 V
- IP3 43 dBm Typical @ +3 V
- Low Insertion Loss (0.3 dB @ 0.9 GHz)
- Low DC Power Consumption
- Available Lead (Pb)-Free MSL-1 @ 250°C per JEDEC J-STD-020
