Data Bus Width
: 8 bit
On-Chip ADC
: Yes
Mounting Style
: SMD/SMT
Operating Supply Voltage
: 1.8 V to 5.5 V
Core
: AVR
Package / Case
: TQFP-64
Operating Temperature Range
: - 40 C to + 85 C
Maximum Clock Frequency
: 8 MHz
Program Memory Size
: 16 KB
Data RAM Size
: 1 KB
Processor Series
: ATMEGA16x
DescriptionThe ATMEGA169PV-8AU is designed as one kind of low-power CMOS 8-bit microcontroller device that has some points of features:(1)High-performance, Low-power AVR 8-bit Microcontroller;(2)32 x 8 General Purpose Working Registers;(3)Boundary-scan Capabilities According to the JTAG Standard;(4)One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture Mode;(5)8-channel, 10-bit ADC;(6)Temperature range is -40°C to 85°C Industrial;(7)Power-on Reset and Programmable Brown-out Detection;(8)External and Internal Interrupt Sources.
The absolute maximum ratings of the ATMEGA169PV-8AU can be summarized as:(1)Operating Temperature: -55°C to +125°C;(2)Storage Temperature: -65°C to +150°C;(3)Voltage on any Pin except RESET with respect to Ground: -0.5V to VCC+0.5V;(4)Voltage on RESET with respect to Ground: -0.5V to +13.0V;(5)Maximum Operating Voltage: 6.0 V;(6)DC Current per I/O Pin: 40.0 mA;(7)DC Current VCC and GND Pins: 400.0 mA. If you want to know more information about the ATMEGA169PV-8AU, please download the datasheet in www.seekic.com or www.chinaicmart.com .
Parameters: | Technical/Catalog Information | ATMEGA169PV-8AU |
| Vendor | Atmel |
| Category | Integrated Circuits (ICs) |
| Program Memory Size | 16K x 8 |
| RAM Size | 1K x 8 |
| Number of I /O | 54 |
| Package / Case | 64-TQFP |
| Speed | 8MHz |
| Controller Series | ATmega |
| Oscillator Type | Internal |
| Packaging | Tray |
| Program Memory Type | FLASH |
| EEPROM Size | 512 x 8 |
| Core Processor | AVR |
| Data Converters | A/D 8x10b |
| Core Size | 8-Bit |
| Operating Temperature | -40°C ~ 85°C |
| Connectivity | SPI, UART/USART, USI |
| Peripherals | Brown-out Detect/Reset, LCD, POR, PWM, WDT |
| Voltage - Supply (Vcc/Vdd) | 1.8 V ~ 5.5 V |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | ATMEGA169PV 8AU
ATMEGA169PV8AU
|
