AWT1921

The AWT1921 is a four stage monolithic amplifier for use in communication systems that require high gain and output intercept point. The device has been specifically designed for fixed satellite access quipment and handest booster amplifier applications. It has many unique features: The first one is high output intercept point. The second one is high linearity. The third one is true surface mount package. The forth one is low cost. The fifth one is off chip output matching circuit allows applicaiton optimization,etc.

There are some electrical specifications about AWT1921(pin with CDMA modulation, fo is 1610-1626.5 MHz, VDS1 is euqal to VDS2 which is euqal to VDS3 or VDS4 that is 9.0 V, Vss is -5 V , Vref is +5 V , Vdd is +5 V , Tc is 25,50 ohms system.).Frequency is 1610 MHz min and 1626.5 MHz max. Power output is 35 dBm min and 36 dBm typ. Power added efficiency is 25% typ. Gain is 27 dB min and 30 dB typ. ACPR is 25 dBc typ and 100 dBc max(0.730 NHz) or is -28 dBc typ and 100 dBc max(1.23 MHz).Stability(60 dBc all surious outputs relative to desired signal) is 3:1 max(VSWR load, all phase angles). Bias supply current: Iss is 15 mA typ. Iref is 5 mA typ. Idd is 15 mA typ. Quiescent current: IDO1 is 60 mA typ. IDQ2 is 90 mA typ. IDQ3 is 150 mA typ. IDQ4 is 200 mA typ. Input return loss is 11 dB typ.Gain flantness is 0.8 dB typ when Pout is +35 dBm.Thermal resistance is 4.5 C/W.

All the information above is just a simple introduction to AWT1921, if you are interested in it or want to know more about it, please pay more attention to our web and you can find more detailed information about it!Thanks for your attention!

The AWT1921 is a four stage monolithic amplifier for use in communication systems that require high gain and output intercept point. The device has been specifically designed for fixed satellite access equipments and handset booster amplifier applications
