Part Number: AZ317L
Description: The AZ317L is an adjustable 3-terminal positive voltage regulator capable of supplying 100mA over a 1....
- Table of contents:
AZ317L
-
Suppliers
DataSheet
General Description
AZ317L General Description
The AZ317L is an adjustable 3-terminal positive voltage regulator capable of supplying 100mA over a 1.2V to 12V output range. This voltage regulator is exceptionally easy to use and requires only two external resistors to set the output voltage. Both line and load regulation are better than standard fixed regulators.
In addition to higher performance than fixed regulators, AZ317L employs overload protection. Included on the chip are current limiting and thermal overload protection. All overload protection circuitry remains fully functional even when the adjustment terminal is disconnected.
The AZ317L is available in standard TO-92 and SOIC- 8 packages.
AZ317L Maximum Ratings
| Parameter |
Symbol |
Value |
Unit |
| Input Voltage |
VIN |
20 |
V |
| Input-Output Voltage Differential |
15 |
V | |
| Operating Junction Temperature |
TJ |
150 |
|
| Storage Temperature Range |
TSTG |
-65 to 150 |
|
| Power Dissipation |
PD |
700 |
mW |
| Lead Temperature (Soldering, 4sec.) |
TLEAD |
260 |
|
| ESD (Human Body Model) |
ESD |
2000 |
V |
| ESD (Machine Model) |
ESD |
200 |
V |
the device. These are stress ratings only, and functional operation of the device at these or any other conditions
beyond those indicated under "Recommended Operating Conditions" is not implied. Exposure to "Absolute Maximum
Ratings" for extended periods may affect device reliability.
AZ317L Features
· Adjustable Output Down to 1.2V
· Guaranteed 100mA Output Current
· Output Short Circuit Protected
· Line Regulation: 0.01%/V
· Load Regulation: 0.1%
· Constant Current Limit over Temperature
· Standard 3-lead Transistor Package
· Input Ripple Rejection: 70dB
· Guaranteed 100mA Output Current
· Output Short Circuit Protected
· Line Regulation: 0.01%/V
· Load Regulation: 0.1%
· Constant Current Limit over Temperature
· Standard 3-lead Transistor Package
· Input Ripple Rejection: 70dB
AZ317L Typical Application
· High Efficiency Linear Regulators
· Post Regulation for Switching Supplies
· Microprocessor Power Supply
· Mother Board I/O Power Supply
· Post Regulation for Switching Supplies
· Microprocessor Power Supply
· Mother Board I/O Power Supply
AZ317L Connection Diagram
AZ317LZ-E1
PDF/DataSheet Download
- Datasheet: AZ317LZ-E1
- File Size: 177780 KB
- Manufacturer: BCD Semiconductor Manufacturing Limited
- Click here to Download
