Purchase BA3632K, In-stock BA3632K From SeekIC.
MFG:ROHM Package Cooled:QFP
Part Number: BA3632K
MFG: ROHM
Package Cooled: QFP
Description: The BA3632K is a dual-channel pre / power system IC designed for 1.5V headphone stereos. There is no n...
- Table of contents:
BA3632K
-
Suppliers
DataSheet
General Description
BA3632K General Description
The BA3632K is a dual-channel pre / power system IC designed for 1.5V headphone stereos. There is no need for DC/DC conversion, and the system can operate off a single battery. The IC draws low current (ICC = 2.6mA) to allow long set life.
BA3632K Features
1) Dual pre-amplifiers with auto reverse compatibility.
2) Dual power amplifiers.
3) Bass boost circuit (variable bass boost).
4) AMS circuit (on chip comparator).
5) Ripple filter.
6) Low power consumption (ICC = 6.8mA, 0.5W 2ch, RL = 32W).
2) Dual power amplifiers.
3) Bass boost circuit (variable bass boost).
4) AMS circuit (on chip comparator).
5) Ripple filter.
6) Low power consumption (ICC = 6.8mA, 0.5W 2ch, RL = 32W).
BA3632K Typical Application
1.5V headphone stereos.
BA3632K
PDF/DataSheet Download
- Datasheet: BA3632K
- File Size: 347187 KB
- Manufacturer: ROHM [Rohm]
- Click here to Download
