BA4114

The BA4114 is a kind of silicon monolithic intergrated circuit.

What comes next is about the BA4114 absolute maximum ratings (T_a=25).The V_CC (supply voltage) is 8.0 V.The P_d (power dissipation) is 550 mW.The T_opr (operating temperature range) is from -20 to 75.The T_stg (storage temperature range) is from -55 to +125.Then is about the operating supply voltage (T_a=25).The V_CC is from 1.8 to 7.0 V.

The following is about the BA4114 electrical characteristics (Ta=25,V_CC=4.0 V,f_IN=10.7 MHz,=±3 kHz,fm=1 kHz).The typical squelch hysterisis is 50 mV.The typical mixer conversion gain is 28 dB.The typical mixer input resistance is 3.3 k.
