BA5210FS
Suppliers
DataSheet
General Description

Purchase BA5210FS, In-stock BA5210FS From SeekIC.

MFG:ROHM Package Cooled:05+ D/C:SSOP-16P

BA5 Series Datasheet download

Five Points

Part Number: BA5210FS

MFG: ROHM

Package Cooled: 05+

D/C: SSOP-16P

Description: The BA5210FS is a power amplifier with a built-in monaural speaker / stereo headphone switch. The speaker drive is BTL ...

BA5210FS General Description

The BA5210FS is a power amplifier with a built-in monaural speaker / stereo headphone switch. The speaker drive is BTL for large output, and when the headphones are connected, the "center-amp" design means that coupling is not required. This significantly reduces the number of external components required, and makes this IC ideal for compact sets that have high component density. Mute and standby functions are provided, and direct microprocessor control is possible.

BA5210FS Features

1) Built-in BTL / stereo switch circuit.
2) Mute function.
3) Standby function.
4) Few external components required.
5) Low current dissipation and good sound quality.

BA5210FS Typical Application

Notebook computers, electronic books, portable CD players, video cameras with built-in monitors, LCD TVs, radios, and electronic instruments

BA5210FS datasheet

BA5210FS
PDF/DataSheet Download

Datasheet: BA5210FS
File Size: 139291 KB
Manufacturer: ROHM [Rohm]
Click here to Download
