Part Number: BA6486FS



MFG: ROHM

Package Cooled: SOP

D/C: 03+

Description: The BA6486FS is a one-chip IC designed for driving 12V FDD spindle motors. This high-performance IC em...


Urgent Purchase

BA6486FS General Description


The BA6486FS is a one-chip IC designed for driving 12V FDD spindle motors. This high-performance IC employs a 3-phase, full-wave soft switching drive system, and contains a digital servo, an index amplifier, and a power save circuit. The compactly packaged IC reduces the number of external components required.

BA6486FS Features

 12V supply voltage.
  3-phase, full-wave soft switching drive system.
  Digital servo circuit.
  Power save circuit.
  Hall power supply switch.
  Motor speed changeable.
  Index amplifier.

BA6486FS Typical Application

Floppy disk drivers
