BAS31

Rectifiers 120V 200mA

product image

BAS31 Picture
See larger image
SeekIC No. : 00168568 Detail

BAS31: Rectifiers 120V 200mA

BAS31 Data Sheet

floor Price/Ceiling Price

US $ .05~.12 / Piece | Get Latest Price
Part Number:
BAS31
Mfg:
Fairchild Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $.12
  • $.1
  • $.08
  • $.05
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/17

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Product : Standard Recovery Rectifiers Configuration : Dual Series
Reverse Voltage : 120 V Forward Voltage Drop : 1.25 V at 0.4 A
Recovery Time : 50 ns Forward Continuous Current : 0.2 A
Max Surge Current : 2 A Reverse Current IR : 0.1 uA
Mounting Style : SMD/SMT Package / Case : SOT-23
Packaging : Reel

Description

Reverse Current IR : 0.1 uA
Mounting Style : SMD/SMT
Packaging : Reel
Product : Standard Recovery Rectifiers
Recovery Time : 50 ns
Max Surge Current : 2 A
Forward Continuous Current : 0.2 A
Package / Case : SOT-23
Configuration : Dual Series
Reverse Voltage : 120 V
Forward Voltage Drop : 1.25 V at 0.4 A


Pinout






Specifications

Symbol Parameter
Value
Unit
WIV Working Inverse Voltage
90
V
IO Average Rectified Current
200
mA
IF DC Forward Current
600
mA
if Recurrent Peak Forward Current
700
mA
if(surge) Peak Forward Surge Current
Pulse width = 1.0 second
Pulse width = 1.0 microsecond

1.0
2.0

A
A
Tstg Storage Temperature Range
-50 to +150
Tj Operating Junction Temperature
150

*These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
NOTES:
1) These ratings are based on a maximum junction temperature of 150 degrees C.
2) These are steady state limits. The factory should be consulted on applications involving pulsed or low duty cycle operations.




Parameters:

Technical/Catalog InformationBAS31
VendorFairchild Optoelectronics Group
CategoryDiscrete Semiconductor Products
Diode Type Standard
Diode Configuration1 Pair Series Connection
Voltage - DC Reverse (Vr) (Max)120V
Current - Average Rectified (Io) (per Diode)200mA
Voltage - Forward (Vf) (Max) @ If1V @ 200mA
Current - Reverse Leakage @ Vr100nA @ 90V
Reverse Recovery Time (trr)50ns
SpeedSmall Signal =< 200mA (Io), Any Speed
Mounting TypeSurface Mount
Package / CaseSOT-23
PackagingTape & Reel (TR)
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names BAS31
BAS31
BAS31FSTR ND
BAS31FSTRND
BAS31FSTR
