BC107

Transistors Bipolar (BJT) NPN Low Noise GP

product image

BC107 Picture
SeekIC No. : 00211928 Detail

BC107: Transistors Bipolar (BJT) NPN Low Noise GP

floor Price/Ceiling Price

Part Number:
BC107
Mfg:
STMicroelectronics
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/3/28

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Transistor Polarity : NPN Collector- Emitter Voltage VCEO Max : 45 V
Emitter- Base Voltage VEBO : 6 V Maximum DC Collector Current : 0.1 A
DC Collector/Base Gain hfe Min : 200 Configuration : Single
Maximum Operating Temperature : + 150 C Mounting Style : Through Hole
Package / Case : TO-18 Packaging : Bulk

Description

Maximum Operating Frequency :
Transistor Polarity : NPN
Configuration : Single
Maximum Operating Temperature : + 150 C
Emitter- Base Voltage VEBO : 6 V
Mounting Style : Through Hole
Collector- Emitter Voltage VCEO Max : 45 V
Maximum DC Collector Current : 0.1 A
Packaging : Bulk
DC Collector/Base Gain hfe Min : 200
Package / Case : TO-18


Features:

The BC107 and BC108 are silicon planar epitaxial NPN transistors in TO-18 metal case. They are suitable for use in driver stages, low noise input stages and signal processing circuits of television reveivers. The PNP complemet for BC107 is BC177.




Specifications

Symbol Parameter
Value
Unit
BC107
BC108
VCBO Collector-Base Voltage (IE = 0)
50
30
V
VCEO Collector-Emitter Voltage (IB = 0)
45
20
V
VEBO Emitter-Base Voltage (IC = 0)
6
5
V
IC Collector Current
100
mA
Ptot
Total Dissipation at Tamb 25
at Tcase 25
0.3
0.75
W
W
Tstg Storage Temperature
-55 to 175
Tj Max. Operating Junction Temperature
175



Parameters:

Technical/Catalog InformationBC107
VendorSTMicroelectronics
CategoryDiscrete Semiconductor Products
Transistor TypeNPN
Voltage - Collector Emitter Breakdown (Max)45V
Current - Collector (Ic) (Max)100mA
Power - Max300mW
DC Current Gain (hFE) (Min) @ Ic, Vce110 @ 2mA, 5V
Vce Saturation (Max) @ Ib, Ic250mV @ 500A, 10mA
Frequency - Transition-
Current - Collector Cutoff (Max)-
Mounting TypeThrough Hole
Package / CaseTO-18
PackagingTube
Drawing Number*
Lead Free StatusContains Lead
RoHS StatusRoHS Non-Compliant
Other Names BC107
BC107
497 3116 5 ND
49731165ND
497-3116-5
