BC847CWT1

Transistor Polarity : NPN
Configuration : Single
Maximum Operating Temperature : + 150 C
Mounting Style : SMD/SMT
Packaging : Reel
Emitter- Base Voltage VEBO : 6 V
Collector- Emitter Voltage VCEO Max : 45 V
Package / Case : SC-70
Maximum DC Collector Current : 0.1 A
Maximum Operating Frequency : 100 MHz (Min)
DC Collector/Base Gain hfe Min : 270 at 10 uA at 5 V


Specifications

Characteristic	Symbol	BC846	BC847	BC848	Unit
Collector-Emitter voltage	VCEO	65	45	30	V
Collector-Base voltage	VCBO	80	50	30	V
Emitter-Base voltage	VEBO	6.0	6.0	5.0	V
Collector Current - Continuous	IC	100	100	00	mAdc

Description

These transistors BC847CWT1 are designed for general purpose amplifier applications. They are housed in the SOT323/SC70 which is designed for low power surface mount applications.
