BCB0812UHN-TP09

BLOWER DC 12V 80X75X30 PWM

product image

BCB0812UHN-TP09 Picture
SeekIC No. : 003439321 Detail

BCB0812UHN-TP09: BLOWER DC 12V 80X75X30 PWM

floor Price/Ceiling Price

US $ 9.6~18.81 / Piece | Get Latest Price
Part Number:
BCB0812UHN-TP09
Mfg:
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~10
  • 10~25
  • 25~50
  • 50~100
  • 100~250
  • 250~500
  • 500~1000
  • Unit Price
  • $18.81
  • $17.21
  • $14.41
  • $13.21
  • $11.61
  • $10.81
  • $10.01
  • $9.6
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/19

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Series: BCB Manufacturer: Delta Product Groups
Fan Type: Blower Size / Dimension: Rectangular/Rounded - 75mm L x 80mm H x 30mm W
Voltage - Rated: 12VDC Power (Watts): 27.6W
Features: PWM Control; Speed Sensor (Tach) RPM: 10800 RPM
Noise: 69.3 dB(A) Static Pressure: 3.675 in H2O (915.4 Pa)
Package / Case : SOT-307 Air Flow: 30.2 CFM (0.855m³/min)
Termination: 4 Wire Leads Bearing Type: Ball

Description

Voltage - Rated: 12VDC
Bearing Type: Ball
Fan Type: Blower
Operating Temperature: 14 ~ 140°F (-10 ~ 60°C)
Features: PWM Control; Speed Sensor (Tach)
Termination: 4 Wire Leads
Manufacturer: Delta Product Groups
Power (Watts): 27.6W
Series: BCB
Size / Dimension: Rectangular/Rounded - 75mm L x 80mm H x 30mm W
RPM: 10800 RPM
Noise: 69.3 dB(A)
Static Pressure: 3.675 in H2O (915.4 Pa)
Air Flow: 30.2 CFM (0.855m³/min)


Parameters:

Technical/Catalog InformationBCB0812UHN-TP09
VendorDelta Product Groups
CategoryUndefined Category
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names BCB0812UHN TP09
BCB0812UHNTP09
