Purchase BFS20W, In-stock BFS20W From SeekIC.
MFG:PHILIPS Package Cooled:SOT323 D/C:01+
Part Number: BFS20W
MFG: PHILIPS
Package Cooled: SOT323
D/C: 01+
Description: NPN medium frequency transistor in a SOT323 (SC-70) plastic package.
- Table of contents:
BFS20W
-
Suppliers
DataSheet
General Description
BFS20W General Description
NPN medium frequency transistor in a SOT323 (SC-70) plastic package.
BFS20W Maximum Ratings
| SYMBOL | PARAMETER | CONDITIONS | MIN. | MAX. | UNIT |
| VCBO | collector-base voltage | open emitter | − | 30 | V |
| VCEO | collector-emitter voltage | open base | − | 20 | V |
| VEBO | emitter-base voltage | open collector | − | 4 | V |
| IC | collector current (DC) | − | 25 | mA | |
| ICM | peak collector current | − | 25 | mA | |
| IBM | peak base current | 200 | mA | ||
| Ptot | total power dissipation | Tamb 25 °C; note 1 | − | 200 | mW |
| Tstg | storage temperature | −65 | +150 | ||
| Tj | junction temperature | − | 150 | ||
| Tamb | operating ambient temperature | −65 | +150 |
BFS20W Features
• Low current (max. 25 mA)
• Low voltage (max. 20 V).
• Very low feedback capacitance (typ. 350 fF).
• Low voltage (max. 20 V).
• Very low feedback capacitance (typ. 350 fF).
BFS20W Typical Application
• IF and VHF applications in thick and thin-film circuits.
BFS20W
PDF/DataSheet Download
- Datasheet: BFS20W
- File Size: 56360 KB
- Manufacturer: PHILIPS [Philips Semiconductors]
- Click here to Download
