BH15MA3WHFV

The BH15MA3WHFV is one member of the BH15MA family which is designed as the auto power save CMOS type series regulator. The absolute maximum ratings of this device can be summarized as:(1)power supply voltage: -0.3 V to +6.5 V;(2)power dissipation: 680 mW;(3)operating temperature range: -40 to +85 ;(4)storage temperature range: -55 to +125 ;(5)maximum junction temperature: +125 .

The electrical characteristics of BH15MA3WHFV can be summarized as:(1)output voltage: Vout=25 mV to Vout+25 mV;(2)circuit current: 40 to 70 uA;(3)circuit current (STBY): 1.0 uA;(4)ripple rejection ratio: 60 dB;(5)input or output voltage difference: 60 to 90 mV;(6)line regulation: 2 to 20 mV;(7)output voltage temperature: +/-100 ppm/. If you want to know more information about it, please download the datasheet in www.seekic.com or www.chinaicmart.com .
