Part Number: BH7760KV





Package Cooled: 95+

D/C: QFP

Description: The BH7760KV contains the complete audio I / O analog block on a single-chip IC. Therefore, all necessary functions for...


Urgent Purchase

BH7760KV General Description


The BH7760KV contains the complete audio I / O analog block on a single-chip IC. Therefore, all necessary functions for a DVC audio analog I / O interface are provided on one chip.

BH7760KV Features

1) Contains the input amplifier, wind noise deletion filter, ALC, 30kHz LPF, line amplifier, stereo headphone amplifier, and BTL monaural speaker amplifier required to configure a analog signal I / O interface (audio I / O) all on one chip.
2) With the internal 3-line serial control decoder circuit, serial control enables the setting of the various modes for the IC.

BH7760KV Typical Application

Portable audio applications
