BSM100GAL120DN2
-
Suppliers
DataSheet
General Description
BSM100GAL120DN2 Maximum Ratings
|
Parameter |
Symbol |
Values |
Unit |
|
Collector-emitter voltage |
VCE |
1200 |
V |
|
Collector-gate voltage, RGS = 20 k |
VCGR |
1000 | |
| Gate-emitter voltage |
VGE |
± 20 | |
|
DC collector current TC = 25 °C TC = 80 °C |
Ic |
150
100 | |
|
Pulsed collector current, tp = 1 ms
TC = 25 °C TC = 80 °C |
Ic puls
|
300
200 |
A |
|
Power dissipation per IGBT TC = 25 °C |
P tot |
800 | |
|
Chip temperature |
Tj |
+ 150 |
°C |
|
Storage temperature |
Tstg |
55 . + 150 |
W |
BSM100GAL120DN2 Features
• Single switch with chopper diode
• Including fast free-wheeling diodes
• Package with insulated metal base plate
• Including fast free-wheeling diodes
• Package with insulated metal base plate
BSM100GAL120DN2
PDF/DataSheet Download
- Datasheet: BSM100GAL120DN2
- File Size: 83162 KB
- Manufacturer: SIEMENS [Siemens Semiconductor Group]
- Click here to Download
- ·BSM100GB120DN2
- SIEMENS [Siemens Semiconductor Group]
- IGBT Power Module (Half-bridge Including fast free-wheeling diodes Package with insulated metal base plate)
