Purchase BUZ74A, In-stock BUZ74A From SeekIC.
MFG:ST Package Cooled:TO-220 D/C:03+
- Table of contents:
BUZ74A
-
Suppliers
DataSheet
General Description
BUZ74A Maximum Ratings
| Parameter | Symbol | Values | Unit |
| Continuous drain current TC =27 |
ID | 2.1 | A |
| Pulsed drain current TC = 25 |
IDpuls | 8.5 | |
| Avalanche current,limited by Tjmax | IAR | 2.4 | |
| Avalanche energy,periodic limited by Tjmax |
EAR |
5 |
mJ |
|
Avalanche energy, single pulse |
EAS | 180 | |
| Gate source voltage | VGS | ± 20 | V |
| Power dissipation TC = 25 |
Ptot | 40 | W |
| Operating temperature | Tj | -55 ... + 150 | |
| Storage temperature | Tstg | -55 ... + 150 | |
| Thermal resistance, chip case | RthJC | 3.1 | K/W |
| Thermal resistance, chip to ambient | RthJA | 75 | |
| DIN humidity category, DIN 40 040 | E | ||
| IEC climatic category, DIN IEC 68-1 | 55 / 150 / 56 |
BUZ74A Features
• N channel
• Enhancement mode
• Avalanche-rated
• Enhancement mode
• Avalanche-rated
BUZ74A
PDF/DataSheet Download
- Datasheet: BUZ74A
- File Size: 205028 KB
- Manufacturer: SIEMENS [Siemens Semiconductor Group]
- Click here to Download
