Purchase C25M, In-stock C25M From SeekIC.
MFG:FWI Package Cooled:TO-220 D/C:2003
- Table of contents:
C25M
-
Suppliers
DataSheet
General Description
C25M Maximum Ratings
| Characteristic | Symbol | C25A | C25B | C25D | C25G | C25J | C25K | C25M | Unit |
| Peak Repetitie Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage |
VRRM |
50 | 100 | 200 | 400 | 600 | 800 | 1000 | V |
| RMS Reverse Voltage | VR(RMS) | 35 | 70 | 140 | 280 | 420 | 560 | 700 | V |
| Average Rectified Output Current @TC=150 | IO | 25 | A | ||||||
| Non-Repetitive Peak Forward Surge Current 8.3ms Single half sine-wave superimposed on rated load(JEDEC Method) |
IFSM | 400 | A | ||||||
| Forward Voltage @IF=50A | VFM | 1.08 | V | ||||||
| Peak Reverse Current At Rated DC Blocking Voltage @TA=25 | IRM | 3.0 | A | ||||||
| Typical Thermal Resistance Junction to Ambient | RJA | 26 | K/W | ||||||
| Operating and Storage Temperature Range | TJ,TSTG | -40 to +150 | |||||||
C25M Features
Diffused Junction
Low Leakage
Low Cost
High Surge Current Capability
Die Size 164 mil HEX
C25M
PDF/DataSheet Download
- Datasheet: C25M
- File Size: 24361 KB
- Manufacturer: WTE [Won-Top Electronics]
- Click here to Download
