CA500

Features:

· Simple Two Lead Current Sources
· 1 to 100 Volt Operation
· Zero Temperature Coefficient
· Simplifies Floating Current Sources
· No Power Supplies Required


Pinout




Specifications

PARAMETERS/TEST CONDITIONS	SYMBOL	LIMIT	UNITS
Peak Operating Voltage	POV	50	V
Forward Current	IF	50	mA
Reverse Current	I R	20
Power Dissipation	PD	360	mW
Power Derating		3.27	mW/
Operating Junction Temperature	TJ	-55 to 150
Storage Temperature	Tstg	-55 to 200

(TA = 25 unless otherwise noted)


Description

Calogic's current regulator diode CA500 is available in plastic TO-92 and surface mount SOT-23. The devices are selected for narrow current ranges and are excellent choices for test instrumentation and medical applications. With nominal current ranges from 0.24mA to 4.7mA, all in 20% bands. CA500 allow the designer a cost effective method of providing a current regulator with no power supply requirements and lower part count. The lower current devices operate at 1 volt.
