See larger image

SeekIC No. : 003446994 Detail

CAV-7.5-3.3: CHOKE COMMON MODE 3.3MH 7.5A VRT

CAV-7.5-3.3 Data Sheet

US $ 5.46~5.46 / Piece | Get Latest Price

Part Number:: CAV-7.5-3.3
Mfg:
Supply Ability:: 5000

Price Break

Qty
0~100

Unit Price
$5.46

Processing time
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2025/12/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

CAV-1.2-10 evaluate
US $1.26 - 1.26 / Piece

CHOKE COM MODE 2X10MH 1.2A VRT
CAV-16-0.15 evaluate
US $4.4 - 4.4 / Piece

TOROIDAL CHOKE 16ADC 0.15MH

Product Details

Quick Details

Series:	CA	Manufacturer:	AlfaMag Electronics, LLC
Filter Type:	Power Line	Number of Lines:	2
Inductance:	3.3mH	Current:	7.5A
DC Resistance (DCR):	16 mOhm	Impedance:	-
Mounting Type:	Through Hole	Size / Dimension:	1.693" L x 1.102" W (43.00mm x 28.00mm)
Height (Max):	1.870" (47.50mm)	Maximum Operating Temperature :	85 C
Package / Case:	Vertical, 4 PC Pin	Operating Temperature:	-40°C ~ 125°C

Description

Number of Lines: 2
Filter Type: Power Line
Operating Temperature: -40°C ~ 125°C
Impedance: -
Mounting Type: Through Hole
Package / Case: Vertical, 4 PC Pin
Packaging: Bulk
Inductance: 3.3mH
Current: 7.5A
DC Resistance (DCR): 16 mOhm
Series: CA
Manufacturer: AlfaMag Electronics, LLC
Size / Dimension: 1.693" L x 1.102" W (43.00mm x 28.00mm)
Height (Max): 1.870" (47.50mm)

Parameters:

Technical/Catalog Information	CAV-7.5-3.3
Vendor	AlfaMag Electronics, LLC
Category	Filters
Inductance	3.3mH
Impedance	-
DC Resistance (DCR)	16.00 mOhm Max
Current	7.5A
Filter Type	Common Mode - 2 Line Array
Mounting Type	Through Hole
Package / Case	1.102" L x 1.693" W x 1.870" H (28.00mm x 43.00mm x 47.50mm)
Packaging	Bulk
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CAV 7 5 3 3 CAV7533
