Product Details

Description



Features:

• On-chip bias resistor: R1 = 1.0 kΩ, R2 = 10 kΩ
• Low power consumption during driving: VOL = 0.12 V @VI = 5.0 V, IC = 0.5 A
• On-chip dumper diode for reverse cable


Specifications

Parameter
Symbol
Ratings
Unit
Collector to base voltage
VCBO
60±10
V
Collector to emitter voltage
VCEO
60±10
V
Emitter to base voltage
VEBO
15
V
Collector current (DC)
IC(DC)
±2.0
A
Collector current (Pulse)
IC(pulse) *
±3.0
A
Base current (DC)
IB(DC)
0.03
A
Total power dissipation
PT
1.0
W
Junction temperature
Tj
150
°C
Storage temperature
Tstg
−55 to +150
°C



Description

The CE2A3Q is a transistor of on-chip high hFE resistor incorporating dumper diode in collector to emitter as protect elements. This transistor is ideal for actuator drives of OA equipments and electric equipments.
