CEP-1173

Driver Circuitry: Transducer, Externally Driven
Operating Mode: Continuous
Washable: No
Packaging: Bulk
Manufacturer: CUI Inc
Termination: Wire Leads
Input Type: DC
Voltage - Rated: 12VDC
Mounting Type: Chassis Mount
Series: CEP
Current - Supply: 7mA
Technology: Piezo (with Feedback)
Voltage Range: 3 ~ 28V
Frequency: 3.3kHz
Sound Pressure Level: 82dB @ 12V, 30cm
Size / Dimension: Circular - 32.00mm Dia x 14.00mm H


Specifications

recommended circuits: click here

resonant frequency: 3.3kHz± 0.5

operating voltage: 3-28 Vdc

current consumption: 7mA

sound pressure level: 82dB

rated voltage: 12 Vdc

operating temperature: -30 to +80°C

storage temperature: -40 to +95°C

diameter: 32.0 mm

depth: 13.5 mm

weight: 7.4 grams

termination: wire leads

640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram">

Parameters:

Technical/Catalog Information	CEP-1173
Vendor	CUI Inc
Category	Audio Products
Type	Piezo Transducer, Self Drive (External Drive with Feedback)
Sound Pressure Level	82dB
Mounting Type	Flange Mount
Capacitance @ Frequency	-
Frequency	3.3kHz
Packaging	Bulk
Operating Mode	Continuous
Voltage Range	3~28VDC
Voltage - Rated	12VDC
Current Rating	7mA
Size / Dimension	Circular - 32mm Dia x 13.5mm H
Termination	Wire Leads
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CEP 1173 CEP1173 102 1149 ND 1021149ND 102-1149
