CLC109 General Description
CLC109 Maximum Ratings
Vcc ±7.0V
Iout output is short circuit protected to
ground, but maximum reliability will be
maintained if Iout does not exceed 30mA
input voltage ±Vcc
maximum junction temperature +150°C
operating temperature range
AJ -40°C to +85°C
A8/AM/AL -55°C to +125°C
storage temperature range -65°C to +150°C
lead temperature (soldering 10 sec) +300°C
ESD rating 1000V
CLC109 Features
High small-signal bandwidth (270MHz)
Low supply current (3.5mA @ ±5V)
Low output impedance (2.8Ω)
350V/µs slew rate
Single supply operation (0 to 3V supply min.)
Evaluation boards and Spice models
CLC109 Typical Application
Video switch buffers
Test point drivers
Low power active filters
DC clamping buffer
High-speed S & H circuits
Inverting op amp input buffer
