CMD17-21VGD/TR8

Illumination Color : Green
Forward Current : 20 mA
Packaging : Reel
Forward Voltage : 2.1 V
Viewing Angle : 140 deg
Wavelength/Color Temperature : 570 nm
Luminous Intensity : 7 mcd
LED Size : 2 mm x 1.25 mm x 1.1 mm
Lens Color/Style : Green Diffused


Pinout




Specifications

Part Number: CMD17-21VGD/TR8
Serial Number: CMD17-21
LED Type: SMT
Industry Size: 805
Metric Size: 2.0 x 1.25 x 1.1 mm
Output Color: GREEN
Epoxy: GREEN DIFFUSED
Peak Wave length (mA): 570
Minimum MCD: 4
Typical MCD: 8
Forward Volt (Typical): 2.1
Forward Volt (Max): 2.8
Rate Current (mA): 20
Viewing Angle (°): 140
Operating Temperature:
Storage Temperature:
Power Dissipation: 105
Cont Forward Current Max: 25
RoHS Status: Yes


Parameters:

Technical/Catalog Information	CMD17-21VGD/TR8
Vendor	CML Innovative Technologies Inc
Category	Optoelectronics
Color	Green
Lens Style/Size	Rectangle, 1.4mm x 1.25mm
Millicandela Rating	7mcd
Voltage - Forward (Vf) Typ	2.1V
Wavelength - Dominant	570nm
Wavelength - Peak	570nm
Current - Test	20mA
Viewing Angle	140°
Lens Type	Diffused
Luminous Flux	29 mlm
Package / Case	0805 (2012 metric)
Mounting Type	Surface Mount
Packaging	Digi-Reel?
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CMD17 21VGD TR8 CMD1721VGDTR8 L62505DKR ND L62505DKRND L62505DKR
