CMI-5247TF-K

Series: -
Manufacturer: CUI Inc
Type: Electret Condenser
Output Type: Analog
S/N Ratio: 60dB
Current - Supply: 500µA
Port Location: Top
Seal Rating: None
Size / Dimension: 9.70mm Dia
Shape: Circular
Packaging: Bulk
Voltage - Rated: 1.5 ~ 10V
Termination: Solder Pads
Direction: Unidirectional
Frequency Range: 70Hz ~ 20kHz
Sensitivity: -47dB ±3dB
Impedance: 680 Ohm
Height (Max): 5.40mm


Specifications

directivity: unidirectional

sensitivity: -47 dB ± 3 dB

sensitivity reduction: -3 dB

operating voltage: 1.5 V dc

output impedance: 680 Ω

operating frequency: 70 ~ 20,000 Hz

current consumption: 0.5 mA

signal to noise ratio: 60 dBA

operating temperature: -20 ~ +70° C

storage temperature: -20 ~ +70° C

dimensions: ?9.7 x 5.2 mm

weight: 0.72 g

material: Al

termination: terminal type

640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram">

Parameters:

Technical/Catalog Information	CMI-5247TF-K
Vendor	CUI Inc
Category	Audio Products
Sensitivity	-47dB ±3dB
Voltage - Rated	1.5 ~ 10VDC
Current	500A
Type	Electret Condenser
Size / Dimension	Circular - 9.7mm Dia x 5.2mm H
Frequency	70Hz ~ 20KHz
S/N Ratio	60dB
Filter Type	-
Impedance	680 Ohm
Termination	Solder Pads
Direction	Unidirectional
Port Location	Top
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CMI 5247TF K CMI5247TFK 102 1728 ND 1021728ND 102-1728
