CP606
-
Suppliers
DataSheet
General Description
CP606 Maximum Ratings
| CP600 | CP601 | CP602 | CP604 | CP606 | CP608 | CP60010 | UNITS | |
| Max Recurrent Peak Reverse Voltage | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | V |
| Max Bridge Input RMS | 35 | 70 | 140 | 280 | 420 | 560 | 700 | V |
| Max DC Blocking Voltage | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | V |
| Max Average Rectified Output at TC=50 * See Fig. 2 at TA=25 ** |
6.0 3.0 |
A A | ||||||
| Peak Forward Surge Current, 8.3ms single half sine-wave superimposed on rated load |
125 | A | ||||||
| Max Forward Voltage Drop per element at 3.0A DC & 25 . See Fig. 3 |
1.1 | V | ||||||
| Max Rev Leakage at rated Dc Blocking Voltage per element at 25 See Fig 4 at100 |
10.0 1.0 |
A mA | ||||||
| I2t Rating for fusing ( t<8.3ms) | 127 | A2Sec | ||||||
| Typical junction capacitance per leg (Note 4) CJ | 186 | PF | ||||||
| Typical Thermal Resistance per leg (Note 3) R JA Typical Thermal Resistance per leg (Note 2) R JL |
22.0 7.3 |
°C/W | ||||||
| Operating Temperature Range TJ | -55 TO +125 | °C | ||||||
| Storage Temperature Range TA | -55 TO +150 | °C | ||||||
CP606 Features
• Plastic package has Underwriters Laboratory Flammability Classification 94V-O .
• Surge Overload Ratings to 125 Amperes.
• Low forward voltage, and reverse leakage.
• Small size , simple installation.
• Reliable low cost construction utilizing molded plastic technique.
