CPE-422AC

Technology: Piezo
Operating Mode: Continuous
Washable: No
Packaging: Bulk
Manufacturer: CUI Inc
Series: CPE
Termination: Wire Leads
Driver Circuitry: Indicator, Internally Driven
Mounting Type: Chassis Mount
Frequency: 3kHz
Current - Supply: 13mA
Input Type: AC, DC
Size / Dimension: Circular - 41.80mm Dia x 22.50mm H
Voltage - Rated: 220VAC
Voltage Range: 60 ~ 250V
Sound Pressure Level: 92dB @ 220V, 30cm


Specifications

operating frequency: 3.0 ± 0.5 kHz

operating voltage: 60 ~ 250 Vac/ Vdc

current consumption: 13 mA

sound pressure level: 92 db

rated voltage: 220 Vac

tone: continuous

operating temperature: -30 ~ +85° C

storage temperature: -40 ~ +95° C

dimensions: ?41.8 x 22.0 mm

weight: 22.5 g

material: ABS UL-94 1/16" high heat (black)

termination: wire type

640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram">

Parameters:

Technical/Catalog Information	CPE-422AC
Vendor	CUI Inc
Category	Audio Products
Type	Piezo Indicator, Internal Drive
Sound Pressure Level	92dB
Mounting Type	Flange Mount
Capacitance @ Frequency	-
Frequency	3kHz
Packaging	Bulk
Operating Mode	Continuous
Voltage Range	60 ~ 250VAC/DC
Voltage - Rated	220VAC
Current Rating	13mA
Size / Dimension	Circular - 41.8mm Dia x 22mm H
Termination	Wire Leads
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CPE 422AC CPE422AC 102 1644 ND 1021644ND 102-1644
