General Description
Cellular Memory (M18) General Description
The Numonyx™ StrataFlash® Cellular Memory (M18) device provides high read and write performance at low voltage on a 16-bit data bus.
The flash memory device has a multi-partition architecture with read-while-program and read-while-erase capability.
The device supports synchronous burst reads up to 108 MHz using ADV# and CLK address-latching on some litho/density combinations and up to 133 MHz using CLK address-latching only on some litho/density combinations. It is listed below in the following table.
Cellular Memory (M18) Maximum Ratings
| Parameter | Min | Max | Unit | Conditions | Notes |
| Temperature under Bias Expanded | -30 | +85 | °C | - | 1 |
| Storage Temperature | 65 | +125 | °C | - | 1 |
| F-VCC Voltage | 2.0 | VCCQ + 2.0 | V | - | 2,3 |
| VCCQ and P-VCC Voltage | 2.0 | VCCQ + 2.0 | V | - | 2,4 |
| Voltage on any input/output signal (except VCC, VCCQ,and VPP) |
2.0 | VCCQ + 2.0 | V | - | 2,4 |
| F-VPP Voltage | 2.0 | +11.5 | V | - | 2,3 |
| ISH Output Short Circuit Current | - | 100 | mA | - | 5 |
| VPPH Time | - | 80 | Hours | - | 6 |
| Block Program/Erase Cycles: Main Blocks | 100,000 | - | Cycles | F-VPP = VCC or F-VPP = VPPH | 6 |
Notes:
1. Temperature is Ambient, not Case.
2. Voltage is referenced to VSS.
3. During signal transitions, minimum DC voltage may undershoot to 2.0 V for periods < 20 ns; maximum DC voltage
may overshoot to VCC (max) + 2.0 V for periods < 20 ns.
4. During signal transitions, minimum DC voltage may undershoot to 1.0 V for periods < 20 ns; maximum DC voltage
may overshoot to VCCQ (max) + 1.0 V for periods < 20 ns.
5. Output shorted for no more than one second. No more than one output shorted at a time.
6. Operation beyond this limit may degrade performance.
Cellular Memory (M18) Features
` High-Performance Read, Program and Erase
- 96 ns initial read access
- 108 MHz with zero wait-state synchronous burst reads: 7 ns clock-to-data output
- 133 MHz with zero wait-state synchronous burst reads: 5.5 ns clock-to-data output
- 8-, 16-, and continuous-word synchronous-burst Reads
- Programmable WAIT configuration
- Customer-configurable output driver impedance
- Buffered Programming:
2.0 s/Word (typ), 512-Mbit 65 nm;
Block Erase: 0.9 s per block (typ)
- 20 s (typ) program/erase suspend
` Architecture
- 16-bit wide data bus
- Multi-Level Cell Technology
- Symmetrically-Blocked Array Architecture
- 256-Kbyte Erase Blocks
- 1-Gbit device: Eight 128-Mbit partitions
- 512-Mbit device: Eight 64-Mbit partitions
- 256-Mbit device: Eight 32-Mbit partitions.
- 128-Mbit device: Eight 16-Mbit partitions.
- Read-While-Program and Read-While-Erase
- Status Register for partition/device status
- Blank Check feature
` Quality and Reliability
- Expanded temperature: 30 °C to +85 °C
- Minimum 100,000 erase cycles per block
- ETOX™ X Process Technology (65 nm)
- ETOX™ IX Process Technology (90 nm)
` Power
- Core voltage: 1.7 V - 2.0 V
- I/O voltage: 1.7 V - 2.0 V
- Standby current: 60 A (typ) for 512-Mbit, 65 nm
- Deep Power-Down mode: 2 A (typ)
- Automatic Power Savings mode
- 16-word synchronous-burst read current:
23 mA (typ) @ 108 MHz; 24 mA (typ) @ 133 MHz
` Software
- Numonyx™ Flash Data Integrator (Numonyx™ FDI) optimized
- Basic Command Set and Extended Command Set compatible
- Common Flash Interface
` Security
- OTP Registers:
64 unique pre-programmed bits
2112 user-programmable bits
- Absolute write protection with VPP = GND
- Power-transition erase/program lockout
- Individual zero-latency block locking
- Individual block lock-down
` Density and Packaging
- Density: 128-, 256-, and 512-Mbit, and 1- Gbit
- Address-data multiplexed and nonmultiplexed interfaces
- x16D (105-ball) Flash SCSP
- x16C (107-ball) Flash SCSP
- 0.8 mm pitch lead-free solder-ball
- 96 ns initial read access
- 108 MHz with zero wait-state synchronous burst reads: 7 ns clock-to-data output
- 133 MHz with zero wait-state synchronous burst reads: 5.5 ns clock-to-data output
- 8-, 16-, and continuous-word synchronous-burst Reads
- Programmable WAIT configuration
- Customer-configurable output driver impedance
- Buffered Programming:
2.0 s/Word (typ), 512-Mbit 65 nm;
Block Erase: 0.9 s per block (typ)
- 20 s (typ) program/erase suspend
` Architecture
- 16-bit wide data bus
- Multi-Level Cell Technology
- Symmetrically-Blocked Array Architecture
- 256-Kbyte Erase Blocks
- 1-Gbit device: Eight 128-Mbit partitions
- 512-Mbit device: Eight 64-Mbit partitions
- 256-Mbit device: Eight 32-Mbit partitions.
- 128-Mbit device: Eight 16-Mbit partitions.
- Read-While-Program and Read-While-Erase
- Status Register for partition/device status
- Blank Check feature
` Quality and Reliability
- Expanded temperature: 30 °C to +85 °C
- Minimum 100,000 erase cycles per block
- ETOX™ X Process Technology (65 nm)
- ETOX™ IX Process Technology (90 nm)
` Power
- Core voltage: 1.7 V - 2.0 V
- I/O voltage: 1.7 V - 2.0 V
- Standby current: 60 A (typ) for 512-Mbit, 65 nm
- Deep Power-Down mode: 2 A (typ)
- Automatic Power Savings mode
- 16-word synchronous-burst read current:
23 mA (typ) @ 108 MHz; 24 mA (typ) @ 133 MHz
` Software
- Numonyx™ Flash Data Integrator (Numonyx™ FDI) optimized
- Basic Command Set and Extended Command Set compatible
- Common Flash Interface
` Security
- OTP Registers:
64 unique pre-programmed bits
2112 user-programmable bits
- Absolute write protection with VPP = GND
- Power-transition erase/program lockout
- Individual zero-latency block locking
- Individual block lock-down
` Density and Packaging
- Density: 128-, 256-, and 512-Mbit, and 1- Gbit
- Address-data multiplexed and nonmultiplexed interfaces
- x16D (105-ball) Flash SCSP
- x16C (107-ball) Flash SCSP
- 0.8 mm pitch lead-free solder-ball
