DA108S1

Recovery Time :
Forward Continuous Current :
Max Surge Current :
Mounting Style : SMD/SMT
Product : Standard Recovery Rectifiers
Packaging : Tube
Reverse Current IR : 2 uA
Forward Voltage Drop : 9 V
Configuration : Array 12
Reverse Voltage : 18 V
Package / Case : SO-8


Features:

·ARRAYOF8OR12DIODES
·LOWINPUT CAPACITANCE
·SUITABLEFOR DIGITAL LINE PROTECTION


Application

·Protectionof logic side of ISDNS-interface.
·Protectionof I/O lines of microcontroller.
·Signal conditioning.


Specifications

Symbol	Parameter		Value	Unit
VRRM	Repetitivepeakreverse voltage(forone singlediode)		18	V
IPP	Repetitivepeak forward current *	8/20 s	12	A
P	Power dissipation		0.73	W
Tstg Tj	Storagetemperature range Maximum operating junction temperature		- 55 to + 150 150
TL	Maximumlead temperaturefor soldering during 10s.		260

Description

DA108S1 is consisted of ARRAY of 8 or 12 diodes configured by cells of 2 diodes, each cell being used to protect signal line from transient overvoltagesby clamping action.


Parameters:

Technical/Catalog Information	DA108S1
Vendor	STMicroelectronics
Category	Circuit Protection
Package / Case	8-SOIC (3.9mm Width)
Packaging	Tube
Technology	Diode Array
Applications	Overload Protection
Number of Circuits	8
Voltage - Working	15V
Voltage - Clamping	-
Power (Watts)	730mW
Drawing Number	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	DA108S1 DA108S1 497 2696 5 ND 49726965ND 497-2696-5
