DF7-5S-3.96DSA Picture
See larger image
SeekIC No. : 004325820 Detail

DF7-5S-3.96DSA: Features: 1. Complete Locking Function Reliable interior lock protects mated connectors from accidental disconnection.2. Increased Contact Retention of Crimped Contacts and Prevention of Incomplete ...

DF7-5S-3.96DSA Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
DF7-5S-3.96DSA
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/18

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

1. Complete Locking Function
    Reliable interior lock protects mated connectors from
    accidental disconnection.
2. Increased Contact Retention of Crimped
    Contacts and Prevention of Incomplete Insertion
    Separate contact retainer increases the contact
    retention, assures and visually confirms the complete contact insertion.
3. Molded-in Contact Retention Tabs
    Handling of terminated contacts during the assembly and
    termination is easier and avoids entangling of wires,
    since there are no protruding metal tabs.
4. Incorrect Insertion Prevention
    Connectors are polarized to assure correct mating with
    corresponding parts.
5.Solder Crack Prevention
   Glass reinforced resin is used in the pin header bodies to
    prevent solder cracks caused by the heat shrinkage.
6. Prevention of Incorrect Board Placement
    Built-in locating posts assure correct connector
    placement and orientation on the board.(2-12 pos.)
7. Supports Sealing after Installation.
    Sealing compound can be applied to the board installed
    connector for distance of 6 mm max. from the mounting
    surface (9 mm max. for single position).
8.Cost Effective Tooling
   The same crimping tools are used to terminate socket
    and pin contacts.
9. Prevention of Short Circuits between Adjacent Contacts
    Each contact is completely surrounded by the insulator
    housing, electrically isolating it from adjacent contacts.
10. 10 A maximum Current
     Connector can carry current of 10 A per contact with
     #16 AWG conductor.Refer to page 3 for current
     ratings for multi-position connectors using other
     conductor sizes.
11. Color Variations
      1 pos. is available in a standard 3 colors: natural,blue, and red.
12. Supports Eyelets
      1 pos. can be mounted to boards which have eyelets attached.


Application

Office equipment, power supplies for industrial, medical and instrumentation applications, variety of consumer electronic and electrical applications.
