Purchase DPX315950DT-5006C1, In-stock DPX315950DT-5006C1 From SeekIC.

MFG:TDK Corporation  Category:RF and RFID

DPX315950DT-5006C1 Product Image

DPX Series Datasheet download

Five Points

Part Number: DPX315950DT-5006C1

Category: RF and RFID

MFG: TDK Corporation





Descriptions: DIPLEXER 2.4/5GHZ W-LAN 1206 SMD

Price Break

2000

Unit Price

1.15000

Extended Price

2300.00

(All prices are in USD) Prices for reference only
Urgent Purchase

DPX315950DT-5006C1 General Description

DIPLEXER 2.4/5GHZ W-LAN 1206 SMD

DPX315950DT-5006C1 Parameters

Technical/Catalog InformationDPX315950DT-5006C1
VendorTDK Corporation
CategoryRF and RFID
Package / Case1206 (3216 metric)
PackagingTape & Reel (TR)
Frequency Bands (Low / High)2.4GHz ~ 2.5GHz / 5GHz ~ 5.95GHz
Low Band Attenuation (min / max dB)21.00dB / -
Return Loss (Low Band / High Band)10dB / 9dB
High Band Attenuation (min / max dB)21.00dB / -
Mounting TypeSurface Mount
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names DPX315950DT 5006C1
DPX315950DT5006C1
445 3262 2 ND
44532622ND
445-3262-2

DPX315950DT-5006C1 datasheet


PDF/DataSheet Download
