Features: 25 MIPS, 40 ns Maximum Instruction Rate Separate On-Chip Buses for Program and Data Memory Program Memory Stores Both Instructions and Data (Three-Bus Performance)Dual Data Address Generators with Modulo and Bit-Reverse AddressingEfficient Program Sequencing with Zero-Overhead Looping: S...
DSP-21xx: Features: 25 MIPS, 40 ns Maximum Instruction Rate Separate On-Chip Buses for Program and Data Memory Program Memory Stores Both Instructions and Data (Three-Bus Performance)Dual Data Address Generat...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
US $123.59 - 123.59 / Piece
Interface Modules Serial PCMCIA Card 2 port RS-422/485
Supply Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . 0.3 V to +7 V
Input Voltage . . . . . . . . . . . . . . . . . . . . .. 0.3 V to VDD + 0.3 V
Output Voltage Swing . . . . . . . . . . ... . . . 0.3 V to VDD + 0.3 V
Operating Temperature Range (Ambient) . . . 55ºC to +125ºC
Storage Temperature Range . . . . . . . . . . . . . 65ºC to +150ºC
Lead Temperature (10 sec) PGA . . . . . . . . . . .... . . . . . . +300ºC
Lead Temperature (5 sec) PLCC, PQFP, TQFP . ...... ..... . +280ºC
*Stresses greater than those listed above may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions greater than those indicated in the operational sections of this specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
The ADSP-2100 Family processors are single-chip microcomputers optimized for digital signal processing (DSP) and other high speed numeric processing applications. The ADSP-21xx processors are all built upon a common core. Each processor combines the core DSP architecture-computation units, data address generators, and program sequencer-with differentiating features such as on-chip program and data memory RAM, a programmable timer, one or two serial ports, and, on the ADSP-2111, a host interface port.
