Purchase DTB113EKT146, In-stock DTB113EKT146 From SeekIC.

MFG:Rohm Semiconductor  Category:Discrete Semiconductor Products

DTB113EKT146

DTB Series Datasheet download

Five Points

Part Number: DTB113EKT146

Category: Discrete Semiconductor Products

MFG: Rohm Semiconductor





Descriptions: TRANS DIGITAL PNP 50V 500MA SMT3

Price Break

3000
6000
12000
27000
51000
102000

Unit Price

.08800
.08300
.07600
.07100
.06500
.06100

Extended Price

264.00
498.00
912.00
1917.00
3315.00
6222.00

(All prices are in USD) Prices for reference only
Urgent Purchase

DTB113EKT146 General Description

TRANS DIGITAL PNP 50V 500MA SMT3

DTB113EKT146 Parameters

Technical/Catalog InformationDTB113EKT146
VendorRohm Semiconductor
CategoryDiscrete Semiconductor Products
Transistor TypePNP - Pre-Biased
Voltage - Collector Emitter Breakdown (Max)50V
Current - Collector (Ic) (Max)500mA
Power - Max200mW
Resistor - Base (R1) (Ohms)1K
Resistor - Emitter Base (R2) (Ohms)1K
Vce Saturation (Max) @ Ib, Ic300mV @ 2.5mA, 50mA
Current - Collector Cutoff (Max)-
DC Current Gain (hFE) (Min) @ Ic, Vce33 @ 50mA, 5V
Frequency - Transition200MHz
Mounting TypeSurface Mount
Package / CaseSC-59-3, SMT3, SOT-346, TO-236
PackagingTape & Reel (TR)
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names DTB113EKT146
DTB113EKT146
DTB113EKT146TR ND
DTB113EKT146TRND
DTB113EKT146TR

DTB113EKT146 datasheet
