The EPM7128SQI100-15N is one member of the EPM7128S family which is designed as the high-density, high-performance PLD. This family including the EPM7128E, EPM7160E, EPM7192E, and EPM7256E devices, all of these devices have several enhanced features: additional global clocking, additional output enable controls, enhanced interconnect resources, fast input registers, and a programmable slew rate.
Features of the EPM7128SQI100-15N are:(1)PCI-compliant devices available;(2)5-ns pin-to-pin logic delays with up to 175.4-MHz counter frequencies (including interconnect);(3)complete EPLD family with logic densities ranging from 600 to 5,000 usable gates;(4)includes 5.0-V MAX 7000 devices and 5.0-V ISP-based MAX 7000S devices;(5)open-drain output option in MAX 7000S devices;(6)programmable power-saving mode for a reduction of over 50% in each macrocell;(7)programmable security bit for protection of proprietary designs.etc.
The absolute maximum ratings of the EPM7128SQI100-15N can be summarized as:(1)supply voltage:-2.0 to 7.0 V;(2)DC input voltage:-2.0 to 7.0 V;(3)DC output current, per pin:-25 to 25 mA;(4)storage temperature:-65 to 150 °C;(5)ambient temperature:-65 135 °C;(6)junction temperature (ceramic packages, under bias):150;(7)junction temperature (PQFP and RQFP packages, under bias):135. If you want to know more information such as the electrical characteristics about the EPM7128SQI100-15N, please download the datasheet in www.seekic.com or www.chinaicmart.com .
