Position: Home > Datasheet list > EVQ Series > Index E > EVQ-PNF05M
Electronica China

Purchase EVQ-PNF05M, In-stock EVQ-PNF05M From SeekIC.

MFG:Panasonic - ECG (VA)  Category:Switches

EVQ-PNF05M

EVQ Series Datasheet download

Five Points

Part Number: EVQ-PNF05M

Category: Switches

MFG: Panasonic - ECG (VA)





Descriptions: SWITCH LT TOUCH 6X3.5 160GF SMD

Price Break

1
10
100
500

Unit Price

.92000
.69300
.60030
.46180

Extended Price

0.92
6.93
60.03
230.90

(All prices are in USD) Prices for reference only
Urgent Purchase

EVQ-PNF05M General Description

SWITCH LT TOUCH 6X3.5 160GF SMD

EVQ-PNF05M Parameters

Technical/Catalog InformationEVQ-PNF05M
VendorPanasonic - ECG (VA)
CategorySwitches
Actuator TypeStandard
CircuitSPST-NO
Contact Rating @ Voltage0.05A @ 12VDC
Mounting TypeSurface Mount
Operating Force160gf
OrientationVertical
Outline6.00mm x 3.50mm
Switch FunctionOff-Mom
IlluminationNon-Illuminated
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names EVQ PNF05M
EVQPNF05M
P13598SCT ND
P13598SCTND
P13598SCT

EVQ-PNF05M datasheet

EVQ21304M
PDF/DataSheet Download

  • Datasheet: EVQ21304M
  • File Size: 166988 KB
  • Manufacturer: PANASONIC [Panasonic Semiconductor]
  • Click here to Download
