F65530A

The F65530A is a member of the F65530 family that designed as one kind of single-chip CMOS LSI circuit which operates as a full-duplex pin-selectable 1200, 2400 or 4800 baud FFSK Modem.It includes on chip circuitry for Carrier Detect and Rx Clock recovery, both of which are made available as output pins and demonstrates a high sensitivity and good bit-error-rate under adverse signal conditions.

Features of the F65530A are:(1)selectable data rates 1200, 2400 and 4800 baud;(2)full-duplex FFSK;(3)Rx and Tx bandpass filters;(4)clock recovery and carrier detect facilities;(5)Rx and Tx enable functions;(6)pin selected Xtal/clock inputs 1.008MHz or 4.032MHz;(7)radio and general applications such as data-over-radio,PMR and cellular signalling,portable data terminals and personal/cordless telephone.

The absolute maximum ratings of the F65530A can be summarized as:(1)supply voltage:-0.3 to 7.0V;(2)input voltage at any pin (ref Vss=0 V):;-0.3 to (VDD+0.3 V)(3)sink/source current (supply pins):+/- 30mA;(4)sink/source current (other pins):+/- 20mA;(5)total device dissipation @ TAMB 25°C:800mW max.;(6)operating temperature range:-30°C to +70°C (plastic);(7)storage temperature range:-40°C to +85°C (plastic).If you want to know more information such as the electrical characteristics about the F65530A,please download the datasheet in www.seekic.com or www.chinaicmart.com .
