Features: • Low dropout voltage• Load regulation: 0.05% typical• On-chip thermal limiting• SO-8 and 5-lead SPAK and TO-252 DPAK packages• Fixed 3.3V, and adjustable or 2.5V or 1.8V fixed• Stable with low ESR output capacitorsApplication• Hard Disk Dr...
FAN1537: Features: • Low dropout voltage• Load regulation: 0.05% typical• On-chip thermal limiting• SO-8 and 5-lead SPAK and TO-252 DPAK packages• Fixed 3.3V, and adjustable or ...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Parameter | Min. | Max. | Unit |
VIN | 10 | V | |
Operating Junction Temperature Range | 0 | 150 | °C |
Storage Temperature Range | -65 | 150 | °C |
Lead Temperature |
The FAN1537 provides 2 output voltages: 3.3V, and either adjustable or 2.5V or 1.8V fixed with 1.0A each output current capability. These devices have been optimized for low voltage where transient response and minimum input voltage are critical.
Current limit features protect the outputs against short circuit currents. On-chip thermal limiting provides protection against any combination of overload and ambient tempera-ture that would create excessive junction temperatures.
