FAN7888

The FAN7888 is a monolithic three half-bridge gate-driveIC designed for high-voltage, high-speed driving MOSFETsand IGBTs operating up to +200V.

Fairchild?s high-voltage process and common-modenoise canceling technique provide stable operation ofhigh-side drivers under high-dv/dt noise circumstances.

An advanced level-shift circuit allows high-side gatedriver operation up to V_S = -9.8V (typical) for V_BS =15V.

The UVLO circuits prevent malfunction when V_DD andV_BS are lower than the specified threshold voltage.

Output drivers typically source/sink 350mA/650mA,respectively, which is suitable for three-phase half-bridgeapplications in motor drive systems.
