MFG:Fairchild Semiconductor (VA)  Category:Discrete Semiconductor Products

FDB3672_F085 Product Image

FDB Series Datasheet download

Five Points

Part Number: FDB3672_F085

Category: Discrete Semiconductor Products

MFG: Fairchild Semiconductor (VA)





Descriptions: MOSFET N-CH 100V 44A D2PAK

Price Break

1
10
100
250

Unit Price

1.65000
1.32000
.99000
.92400

Extended Price

1.65
13.20
99.00
231.00

(All prices are in USD) Prices for reference only
Urgent Purchase

FDB3672_F085 General Description

MOSFET N-CH 100V 44A D2PAK

FDB3672_F085 Parameters

Technical/Catalog InformationFDB3672_F085
VendorFairchild Semiconductor (VA)
CategoryDiscrete Semiconductor Products
Mounting TypeSurface Mount
FET PolarityN-Channel
Drain to Source Voltage (Vdss)100V
Current - Continuous Drain (Id) @ 25° C44A
Rds On (Max) @ Id, Vgs28 mOhm @ 44A, 10V
Input Capacitance (Ciss) @ Vds 1710pF @ 25V
Power - Max120W
PackagingDigi-Reel?
Gate Charge (Qg) @ Vgs31nC @ 10V
Package / CaseD²Pak, SMD-220, TO-263 (2 leads + tab)
FET FeatureStandard
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names FDB3672_F085
FDB3672_F085
FDB3672_F085DKR ND
FDB3672_F085DKRND
FDB3672_F085DKR
