FST16232

The Fairchild Switch FST16232 is a 16-bit to 32-bit highspeed CMOS TTL-compatible synchronous multiplexer/demultiplexer bus switch. The low on resistance of the switch allows inputs to be connected to outputs without adding propagation delay or generating additional ground bounce noise.

The FST16232 allows two separate datapaths to be multiplexed onto, or demultiplexed from, a single path. Two control select pins (S1, S0) are synchronous and clocked on the rising edge of CLK when CLKEN is LOW.
