FX2C-100S-1.27DSA(71), US $ 2.42-3.88 , Hirose Connector, FX2C-100S-1.27DSA(71) DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 002124638 Detail

FX2C-100S-1.27DSA(71): Board to Board / Mezzanine Connectors RCP 100 POS 2.54mm Solder ST Thru-Hole

FX2C-100S-1.27DSA(71) Data Sheet

US $ 2.42~3.88 / Piece | Get Latest Price

Part Number:: FX2C-100S-1.27DSA(71)
Mfg:: Hirose Connector
Supply Ability:: 5000

Price Break

Qty
0~1
1~25
25~100
100~250

Unit Price
$3.88
$3.26
$2.91
$2.42

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/5/4

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

FX2C-100P-1.27DSA evaluate
CONN HEADER VERT 100POS 1.27MM
FX2C-100P-1.27DSA(71) evaluate
US $2.16 - 4.08 / Piece

Board to Board / Mezzanine Connectors HDR 100 POS 2.54mm Solder ST Thru-Hole
FX2C-100S-1.27DSA evaluate
CONN RECEPT VERT 100POS 1.27MM

Product Details

Quick Details

Series :	FX2	Product Type :	Receptacles
Pitch :	1.27 mm	Stack Height :	12 mm
Mounting Style :	Through Hole	Mounting Angle :	Straight
Number of Positions / Contacts :	100	Number of Rows :	1
Housing Material :	Polyamide (PA)	Contact Material :	Phosphor Bronze
Contact Plating :	Gold	Voltage Rating :	125 V
Current Rating :	0.5 A

Description

Product Type : Receptacles
Contact Material : Phosphor Bronze
Contact Plating : Gold
Housing Material : Polyamide (PA)
Current Rating : 0.5 A
Pitch : 1.27 mm
Mounting Angle : Straight
Number of Positions / Contacts : 100
Voltage Rating : 125 V
Mounting Style : Through Hole
Number of Rows : 1
Series : FX2
Stack Height : 12 mm

Parameters:

Technical/Catalog Information	FX2C-100S-1.27DSA(71)
Vendor	Hirose Electric Co Ltd
Category	Connectors
Connector Type	Receptacle, Outer Shroud Contacts
Number of Positions	100
Number of Rows	2
Contact Finish	Gold
Mounting Type	Through Hole
Pitch	0.050" (1.27mm)
Features	-
Packaging	Tray
Contact Finish Thickness	-
Height Above Board	0.374" (9.50mm)
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	FX2C 100S 1 27DSA 71 FX2C100S127DSA71 H10599 ND H10599ND H10599
