Part Number: G6402









Description: The G6402 provides the designer with the best combination of fast switching, low on-resistance and cos...


Urgent Purchase

G6402 General Description


The G6402 provides the designer with the best combination of fast switching, low on-resistance and cost-effectiveness.

The G6402 is universally preferred for all commercial-industrial surface mount applications and suited for low voltage applications such as DC/DC converters.

G6402 Maximum Ratings

Symbol
Parameter
Ratings
Unit
VDS Drain-Source Voltage
-20
V
VGS Gate-to-Source Voltage
±12
V
ID @ TA= 25 Continuous Drain Current3
-4.2
A
ID @ TC= 70 Continuous Drain Current3
-3.4
A
IDM Repetitive Peak Current1,2
-10
A
PD @TA= 25 Power Dissipation
1.38
W
  Linear Derating Factor
0.01
W/
TJ,TSTG Junction and Storage Temperature Range
-55 to + 150
Notes: 1. Pulse width limited by Max. junction temperature.
2. Pulse width300us, duty cycle2%.
3. Surface mounted on 1 in2 copper pad of FR4 board;270/w when mounted on min. copper pad.

G6402 Features

*Ultra Low RDS(ON)
*Fast Switching

G6402 Typical Application

*Power Management in Notebook Computer
*Portable Equipment
*Battery Powered System.
