G901 Maximum Ratings
Input Voltage.................................................................10V
Power Dissipation Internally Limited (Note2)
Maximum Junction Temperature..................................150
Storage Temperature Range.................-65 TJ +150
Lead Temperature, Time for Wave Soldering
SOT89 Package.....................................................260, 4s
Continuous Power Dissipation (TA = + 25)
SOT 89(1).....................................................................0.5W
Note (1): See Recommended Minimum Footprint.
G901 Features
·Dropout voltage typically 0.45V @ IO = 300mA
·Output current in excess of 300mA
·Output voltage accuracy +3%
·Quiescent current, typically 0.6mA
·Internal short circuit current limit
·Internal over temperature protection
G901 Typical Application
·CD-ROM
·Modem
·LAN Hub
·Networking Appliances
·Mouse
·Keyboard
