GB150TS60NPbF

The GB150TS60NPbF is designed as one kind of INT-A-PAK "half-bridges" (ultrafast speed IGBT) with current of 138A. GB150TS60NPbF's benefits include benchmark efficiency for UPS and welding application, rugged transient performance, direct mounting on heatsink and very low junction to case thermal resistance.

GB150TS60NPbF has twelve features. (1)Generation 5 non punch through (NPT) technology. (2)Ultrafast: optimized for hard switching speed 8 kHz to 60 kHz. (3)Low Vce(on). (4)10s short circuit capability. (5)Square RBSOA. (6)Positive Vce(on) temperature coefficient. (7)HEXFRED antiparallel diode with ultrasoft reverse recovery characteristics. (8)Industry standard package. (9)Al2O3 DBC. (10)UL approved file E78996. (11)Compliant to RoHS directive 2002/95/EC. (12)Designed for industrial level. Those are all the main features.

Some absolute maximum ratings of GB150TS60NPbF have been concluded into several points as follow. (1)Its collector to emitter voltage would be 600V. (2)Its continuous collector current would be 138A at Tc=25°C and would be 93A at tc=80°C. (3)Its pulsed collector current would be 300A. (4)Its clamped inductive load current would be 300A. (5)Its diode continuous forward current would be 178A at Tc=25°C and would be 121A at Tc=80°C. (6)Its gate to emitter voltage would be +/-20V. (7)Its maximum power dissipation would be 500W at Tc=25°C and would be 280W at Tc=80°C. (8)Its isolation voltage would be 2500V. It should be noted that stresses above those listed in absolute maximum ratings may cause permanent damage to device.

Also some electrical characteristics of GB150TS60NPbF are concluded as follow. (1)Its collector to emitter breakdown voltage would be min 600V. (2)Its gate threshold voltage would be min 3V, typ 4.2V and max 6V. (3)Its collector to emitter leakage current would be typ 0.01mA, max 0.2mA at Vge=0V, Vce=600V and would be typ 7.5mA, max 15mA at Vge=0V, Vce=600V, Tj=150°C. At present we have not got so much information about this IC and we would try hard to get more information about it. If you have any question or suggestion or want to know more information about GB150TS60NPbF please contact us for details. Thank you!
