GBPC3508W

Bridge Rectifiers 35A Bridge Rectifier

product image

GBPC3508W Picture
See larger image
SeekIC No. : 00132560 Detail

GBPC3508W: Bridge Rectifiers 35A Bridge Rectifier

GBPC3508W Data Sheet

floor Price/Ceiling Price

US $ 1.13~1.53 / Piece | Get Latest Price
Part Number:
GBPC3508W
Mfg:
Fairchild Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $1.53
  • $1.37
  • $1.25
  • $1.13
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Product : Single Phase Bridge Peak Reverse Voltage : 800 V
Maximum RMS Reverse Voltage : 560 V Forward Continuous Current : 35 A
Max Surge Current : 400 A Forward Voltage Drop : 1.1 V
Maximum Reverse Leakage Current : 5 uA Power Dissipation : 83.3 W
Maximum Operating Temperature : + 150 C Length : 29 mm
Width : 29 mm Height : 11.23 mm
Mounting Style : Through Hole Package / Case : GBPC-W
Packaging : Bulk

Description

Product : Single Phase Bridge
Maximum Operating Temperature : + 150 C
Mounting Style : Through Hole
Max Surge Current : 400 A
Peak Reverse Voltage : 800 V
Maximum RMS Reverse Voltage : 560 V
Forward Voltage Drop : 1.1 V
Maximum Reverse Leakage Current : 5 uA
Packaging : Bulk
Package / Case : GBPC-W
Forward Continuous Current : 35 A
Power Dissipation : 83.3 W
Length : 29 mm
Width : 29 mm
Height : 11.23 mm


Specifications

Part Number GBPC3508W
Total Capacitance CT (pF) 300
Max Average Rectified Current IO (A) 35
Peak Repetitive Reverse Voltage VRRM (V) 800
Peak Forward Surge Current IFSM (A) 400
Forward Voltage Drop VF (V) 1.1
Max Reverse Current IR (µA) 5





Parameters:

Technical/Catalog InformationGBPC3508W
VendorFairchild Semiconductor
CategoryDiscrete Semiconductor Products
Diode Type Single Phase
Package / CaseGBPC-W
PackagingTray
Reverse Recovery Time (trr)-
SpeedStandard Recovery >500ns, > 200mA (Io)
Current - DC Forward (If)35A
Voltage - Peak Reverse (Max)800V
Mounting TypeThrough Hole
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names GBPC3508W
GBPC3508W
