GFG1350F

The GFG1350F is designed as one kind of very small, low cost, filter device that is intended for use with A-D and D-A video converters where some deviation from full multicodec standards is allowed. The cut off rate is slower than recommended to reduce time domain ringing. Also this device is designed for use in systems adhering to the EBU standard for 4:2:2 A-D and D-A conversion i.e. sampling rates of 13.5 MHz for the luminance (Y) channel and 6.75 MHz for the chrominance (U and V) channels.

The electrical characteristics of the GFG1350F can be summarized as:(1)Filter Shape: Lowpass;(2)Passband Shape: Flat;(3)Sampling Frequency: 13.5 MHz;(4)Insertion Loss at 100 kHz: < 1.5 dB;(5)End Of Passband: 5.2 MHz;(6)Passband Amplitude Ripple: 0.1 dB max;(7)Loss at half S.F.: 12 dB +/- 2 dB;(8)Start Of Stopband: 8.6 MHz;(9)Stopband Attenuation: 40 dB min;(10)Delay Time at 200 kHz: 200 ns +/- 5 ns;(11)Pulse and bar: K - rating is 1%;(12)Impedance: 75 ohms;(13)Temperature Range: 0°C to 70°C. If you want to know more information such as the electrical characteristics about the GFG1350F, please download the datasheet in www.seekic.com or www.chinaicmart.com.
